MCP server exposition

MCP Http Plugin

Configuration

{
  "_loc": {
    "tenant": "default",
    "teams": [
      "default"
    ]
  },
  "id": "route_2629d12c2-130b-42d5-aba5-b584b95961c9",
  "name": "MCP HTTP server exposition",
  "description": "MCP HTTP server exposition",
  "tags": [],
  "metadata": {},
  "enabled": true,
  "debug_flow": false,
  "export_reporting": false,
  "capture": false,
  "groups": [
    "default"
  ],
  "bound_listeners": [],
  "frontend": {
    "domains": [
      "mcp-http-expo.oto.tools"
    ],
    "strip_path": true,
    "exact": false,
    "headers": {},
    "query": {},
    "methods": []
  },
  "backend": {
    "targets": [
      {
        "id": "target_1",
        "hostname": "request.otoroshi.io",
        "port": 443,
        "tls": true,
        "weight": 1,
        "predicate": {
          "type": "AlwaysMatch"
        },
        "protocol": "HTTP/1.1",
        "ip_address": null,
        "tls_config": {
          "certs": [],
          "trusted_certs": [],
          "enabled": false,
          "loose": false,
          "trust_all": false
        }
      }
    ],
    "root": "/",
    "rewrite": false,
    "load_balancing": {
      "type": "RoundRobin"
    },
    "client": {
      "retries": 1,
      "max_errors": 20,
      "retry_initial_delay": 50,
      "backoff_factor": 2,
      "call_timeout": 30000,
      "call_and_stream_timeout": 120000,
      "connection_timeout": 10000,
      "idle_timeout": 60000,
      "global_timeout": 30000,
      "sample_interval": 2000,
      "proxy": {},
      "custom_timeouts": [],
      "cache_connection_settings": {
        "enabled": false,
        "queue_size": 2048
      }
    },
    "health_check": {
      "enabled": false,
      "url": "",
      "timeout": 5000,
      "healthyStatuses": [],
      "unhealthyStatuses": []
    }
  },
  "backend_ref": null,
  "plugins": [
    {
      "enabled": true,
      "debug": false,
      "plugin": "cp:otoroshi.next.plugins.OverrideHost",
      "include": [],
      "exclude": [],
      "config": {},
      "bound_listeners": [],
      "plugin_index": {
        "transform_request": 0
      },
      "nodeId": "cp:otoroshi.next.plugins.OverrideHost"
    },
    {
      "enabled": true,
      "debug": false,
      "plugin": "cp:otoroshi_plugins.com.cloud.apim.otoroshi.extensions.aigateway.plugins.McpRespEndpoint",
      "include": [],
      "exclude": [],
      "config": {
        "name": "first-mcp-http-server",
        "version": "1.0.0",
        "refs": [
          "tool-function_0511ff44-0ce5-487d-aa1c-d1980ac9a4b8"
        ],
        "mcp_refs": []
      },
      "bound_listeners": [],
      "plugin_index": {},
      "nodeId": "cp:otoroshi_plugins.com.cloud.apim.otoroshi.extensions.aigateway.plugins.McpRespEndpoint"
    }
  ],
  "kind": "proxy.otoroshi.io/Route"
}

MCP SSE Plugin

Configuration

{
  "_loc": {
    "tenant": "default",
    "teams": [
      "default"
    ]
  },
  "id": "route_73e79129a-1cc6-4473-970a-b80905e80c7b",
  "name": "mcp-sse-exposition",
  "description": "mcp-sse-exposition",
  "tags": [],
  "metadata": {},
  "enabled": true,
  "debug_flow": false,
  "export_reporting": false,
  "capture": false,
  "groups": [
    "default"
  ],
  "bound_listeners": [],
  "frontend": {
    "domains": [
      "mcp-sse-exposition.oto.tools"
    ],
    "strip_path": true,
    "exact": false,
    "headers": {},
    "query": {},
    "methods": []
  },
  "backend": {
    "targets": [
      {
        "id": "target_1",
        "hostname": "request.otoroshi.io",
        "port": 443,
        "tls": true,
        "weight": 1,
        "predicate": {
          "type": "AlwaysMatch"
        },
        "protocol": "HTTP/1.1",
        "ip_address": null,
        "tls_config": {
          "certs": [],
          "trusted_certs": [],
          "enabled": false,
          "loose": false,
          "trust_all": false
        }
      }
    ],
    "root": "/",
    "rewrite": false,
    "load_balancing": {
      "type": "RoundRobin"
    },
    "client": {
      "retries": 1,
      "max_errors": 20,
      "retry_initial_delay": 50,
      "backoff_factor": 2,
      "call_timeout": 30000,
      "call_and_stream_timeout": 120000,
      "connection_timeout": 10000,
      "idle_timeout": 60000,
      "global_timeout": 30000,
      "sample_interval": 2000,
      "proxy": {},
      "custom_timeouts": [],
      "cache_connection_settings": {
        "enabled": false,
        "queue_size": 2048
      }
    },
    "health_check": {
      "enabled": false,
      "url": "",
      "timeout": 5000,
      "healthyStatuses": [],
      "unhealthyStatuses": []
    }
  },
  "backend_ref": null,
  "plugins": [
    {
      "enabled": true,
      "debug": false,
      "plugin": "cp:otoroshi.next.plugins.OverrideHost",
      "include": [],
      "exclude": [],
      "config": {},
      "bound_listeners": [],
      "nodeId": "cp:otoroshi.next.plugins.OverrideHost",
      "plugin_index": {
        "transform_request": 0
      }
    },
    {
      "plugin_index": {},
      "nodeId": "cp:otoroshi_plugins.com.cloud.apim.otoroshi.extensions.aigateway.plugins.McpSseEndpoint-0",
      "plugin": "cp:otoroshi_plugins.com.cloud.apim.otoroshi.extensions.aigateway.plugins.McpSseEndpoint",
      "enabled": true,
      "debug": false,
      "include": [],
      "exclude": [],
      "bound_listeners": [],
      "config": {
        "name": "mcp-sse",
        "version": "1.0.0",
        "refs": [
          "tool-function_0511ff44-0ce5-487d-aa1c-d1980ac9a4b8"
        ],
        "mcp_refs": []
      }
    }
  ],
  "kind": "proxy.otoroshi.io/Route"
}

MCP WebSocket Plugin

Configuration

{
  "_loc": {
    "tenant": "default",
    "teams": [
      "default"
    ]
  },
  "id": "route_62c427cac-43c9-4d86-bab4-56cb0b61040b",
  "name": "mcp-websocket-exposition",
  "description": "mcp-websocket-exposition",
  "tags": [],
  "metadata": {},
  "enabled": true,
  "debug_flow": false,
  "export_reporting": false,
  "capture": false,
  "groups": [
    "default"
  ],
  "bound_listeners": [],
  "frontend": {
    "domains": [
      "mcp-websocket-exposition.oto.tools"
    ],
    "strip_path": true,
    "exact": false,
    "headers": {},
    "query": {},
    "methods": []
  },
  "backend": {
    "targets": [
      {
        "id": "target_1",
        "hostname": "request.otoroshi.io",
        "port": 443,
        "tls": true,
        "weight": 1,
        "predicate": {
          "type": "AlwaysMatch"
        },
        "protocol": "HTTP/1.1",
        "ip_address": null,
        "tls_config": {
          "certs": [],
          "trusted_certs": [],
          "enabled": false,
          "loose": false,
          "trust_all": false
        }
      }
    ],
    "root": "/",
    "rewrite": false,
    "load_balancing": {
      "type": "RoundRobin"
    },
    "client": {
      "retries": 1,
      "max_errors": 20,
      "retry_initial_delay": 50,
      "backoff_factor": 2,
      "call_timeout": 30000,
      "call_and_stream_timeout": 120000,
      "connection_timeout": 10000,
      "idle_timeout": 60000,
      "global_timeout": 30000,
      "sample_interval": 2000,
      "proxy": {},
      "custom_timeouts": [],
      "cache_connection_settings": {
        "enabled": false,
        "queue_size": 2048
      }
    },
    "health_check": {
      "enabled": false,
      "url": "",
      "timeout": 5000,
      "healthyStatuses": [],
      "unhealthyStatuses": []
    }
  },
  "backend_ref": null,
  "plugins": [
    {
      "enabled": true,
      "debug": false,
      "plugin": "cp:otoroshi.next.plugins.OverrideHost",
      "include": [],
      "exclude": [],
      "config": {},
      "bound_listeners": [],
      "nodeId": "cp:otoroshi.next.plugins.OverrideHost",
      "plugin_index": {
        "transform_request": 0
      }
    },
    {
      "plugin_index": {},
      "nodeId": "cp:otoroshi_plugins.com.cloud.apim.otoroshi.extensions.aigateway.plugins.McpWebsocketEndpoint-0",
      "plugin": "cp:otoroshi_plugins.com.cloud.apim.otoroshi.extensions.aigateway.plugins.McpWebsocketEndpoint",
      "enabled": true,
      "debug": false,
      "include": [],
      "exclude": [],
      "bound_listeners": [],
      "config": {
        "name": "mcp-server",
        "version": "1.0.0",
        "refs": [
          "tool-function_0511ff44-0ce5-487d-aa1c-d1980ac9a4b8"
        ],
        "mcp_refs": []
      }
    }
  ],
  "kind": "proxy.otoroshi.io/Route"
}
